MIWA LOCK BAN-DS1 series WIRE ELECTRIC LOCK CONTROL BOX

● MIWA BAN-DS1 2-wire electric lock operation panel (replacement for BAN-BS1)
The power supply comes with a household outlet plug, so there is no need for electrical work as long as the plug is near the operating panel.

● Installation of the electric lock requires a high level of expertise (cutting out the door and installing the lock). It is a difficult task for a person with only Sunday carpentry experience.

● If you are unsure about this, please consult a specialist.

◆ Product features

・This is a two-wire, one-line electric lock operation panel that can connect electric locks and operation indicators with two cores.

・The electric lock, electric strike, electromagnetic lock, automatic door, air intake lock, etc. can be operated by operating buttons, and the open/close and lock/unlock status of the door can be checked with the display LED.

・One BAN-DS1 unit can control up to one electric lock, one electric strike, one electromagnetic lock, and one automatic door. Up to two air intake locks can be controlled with one BAN-DS1 unit. (Only in the case of 2-mode control)

・Wiring from the electric lock to the operation panel can be connected with only two wires (non-polarized). The type of connected electric lock can be automatically detected.

・The type of electric lock automatically identified is stored in the memory and will not disappear even if the power is turned off. A compatible 2-wire conversion adapter is required to connect electric locks.

・The control of electric locks can be selected from A, B, and E modes.

・Up to 3 units of 2-wire operation indicator SSP-G series and up to 5 units of 6-wire operation indicator SSP-C series can be connected.

・Electric locks can be controlled by external inputs (no-voltage contact) from intercom, timer, fire alarm system, etc.

・The JEM-A terminal allows easy connection to HA systems.
